PLC-1700 Series

Post-bed, Unison-feed, Lockstitch Machine with Vertical-axis Large Hook

1-Needle type

PLC-1710, PLC-1710-7 (with automatic thread trimmer)

2-Needle type

PLC-1760, PLC-1760L (thick-thread long-pitch type)

PLC-1760-7 (with automatic thread trimmer)

Features

  • Most-advanced machine lineup best suited to the stitching process for heavy weight materials such as car seats and sofas

  • Increased efficiency of feed - The alternating vertical movement mechanism prevents irregular stitches
  • The PLC-1700 Series machines have substantially been improved in their overall "efficiency of feed.
  • The machine smoothly handles large and heavy-weight materials with an increased efficiency of feed, thereby producing consistent seams free from irregular stitches (differences in stitch length).
  • The basic performance (specifications) has been dramatically improved
  • The machine performs sewing with consistency with a broader range of needle counts up to #0. In addition, it achieves the maximum stitch length of 12mm.




Technical Specifications

Model Name PLC-1710-7 PLC-1710 PLC-1760-7 LC-1760 PLC-1760L
Type 1-needle 1-needle 2-needle 2-needle 2-needle
with automatic thread trimmer - with automatic thread trimmer - thick-thread long-pitch type
Sewing speed 2,500 spm

1,800 rpm (P=0~10mm)

1,600 rpm (P=10~12mm)

Needle

134 x 35 Nm110~160

Standard Nm140

134 x 35 Nm140~200

Standard Nm200

Max. stitch length 9mm (forward / backward) 12mm (forward / backward)
Automatic reverse feed function Pneumatic type By lever Pneumatic type By lever By lever
Needle bar stoke 36mm 38mm
Hook Vertical-axis 1.6-fold capacity hook (latch type) Vertical-axis 1.6-fold capacity hook (cap type)
Lubrication Centralized tank method *Lubrication with an oiler for the hook section
