Features :
1. Different speed adjustment of upper and lower wheels is suitable for different elastic materials.
2. Lay-up program segmentation (leading, in-band, with-tail) setting parameters are more flexible.
3. Intelligent belt feeding mechanism, smoother glue sticking, flexible size control for elastic materials.
4. The movement trajectory of the single-axis air nozzle can make the rubber strip fit more efficiently, and the production efficiency is increased by 30%
5. PLC programming control system, simple and stable operation, quick software upgrade.
Technical Specifications:
POWER SUPPLY: AC 220V 50/60HZ
AIR PRESSURE: 0,3-0,5MPA
POWER CONSUMPTION: 3600W
MAX SPEED: 60FT/MIN
NOZZLE WIDTH: 10-30MM, STANDARD: 22MM
DIMENSION: 1200(L)*600(W)*1700(H)MM
NET WEIGHT: 94KG
